Product: 6641 / F level DMD6630/DMD of both upper and lower layers of polyester fiber non-woven, sandwiching a layer of polyester film composite F-class adhesive junction.
Heat class: F (155 ° C)
Other physical properties: 6641 F-class DMD polyester film polyester fiber non-woven fabric flexible composite good mechanical strength, dielectric properties and high heat resistance, color is generally pink, blue and white
Usage: suitable for class F insulation common type and humid with a type of motor slot insulation liner insulation and turn-to-turn insulation, electrical coil insulation can also be used.
Common specifications: 0.15mm, 0.18mm, 0.20mm, 0.25mm, 0.30mm, 0.35mm, 0.40mm
